Product Description

The AMP330 is a precision signal conditioner. It amplifies the low level signal (mV/V) of any strain gauge bridge transducer (pressure, force, torque, displacement) into a high level voltage (up to ±10Vdc) and/or current (4-20mA) signal. Operating from 14 to 26Vdc, it supplies the associated sensor with 5 or 10Vdc regulated power and enables low level signals between 0.5 and 10mV/V to be conditioned. With a bandwidth@-3dB from 1kHz (standard) to 10kHz (option), it is suitable for the most dynamic applications. Zero, gain and signal (voltage or current) settings are accessible to the user.Its compact metal housing makes it particularly suitable for use in mobile applications.
