Very Low Noise Accelerometer IP65/IP67
Product Description
The accelerometers types ASC 5000LN are based on proven MEMS technology and capacitive operating principle. The integrated electronic circuitry enables a differential analog voltage output (±4 V FSO) and flexible power supply voltage from 6 to 40 VDC. The LN (Low Noise) accelerometers from ASC provide an outstanding noise performance from 7 to 400 μg/√Hz which is essential for demanding measurements of smallest frequencies and amplitudes.
5511LN features a lightweight aluminum housing IP65, the 5511LN is rated IP67
5515LN provides a robust stainless-steel housing IP65, the 5515LN is rated IP67
All sensors have an integrated cable with configurable length and connectors. The triaxial accelerometers enable the detection of smallest acceleration amplitudes in three degrees of freedom, for example for measuring aerodynamic and mass-related imbalances in wind turbines or for evaluation ride comfort in passenger ships.
Custom options include Cable Length, Connectors, TEDS Modules and ISO 17025 Calibration
Product Features
Technical Resources
Click the resource buttons below to download the file.
Product Applications
Stock Quantity
| SKU | Product Title | Stock Qty | Lead Time | Unit Price |
|---|
