HIGH IMPACT AND SHOCK 60 SERIES

Product Description

The piezoresistive accelerometers are based proven MEMS technology, in which four variable resistors are configured as a Wheatstone bridge. The uniaxial ASC 61C1, ASC 62C1 and ASC 66C1 feature a wide dynamic range from 0 Hz to 2.5 kHz and outstanding impact resistance up to 5,000 g. In addition, the lightweight design allows its use in applications where the mass load of the test structures has to be minimized.

The sensors feature a lightweight, reliable aluminum housing in different form factors with protection class IP67 for ASC 61C1 and ASC 62C1 as well as a protection class IP65 for ASC 66C1. All accelerometers are equipped with an integrated cable with configurable length and connectors.

Piezoresistive accelerometers are used in high-impact and shock applications such as side and frontal impact tests in the automotive sector. With a measuring range of up to 2,000 g they therefore belong to the category of ASC crash sensors, which can be configured with TEDS and EQX data.
