Product Description

The accelerometers ASC ECO CS-x311 are based on proven MEMS technology and capacitive operating principle and designed for stuctural health monitoring applications. The integrated electronic circuitry enables a single-ended analog current output of 4-20 mA and flexible power supply voltage from 8 to 25 VDC. The models ASC ECO CS series feature broadband noise of <4.5 μA and are used in applications that are requiring extremely long cables (>100 m) or very high EMC immunity. The ECO CS series feature a wide frequency response range from 0Hz to 2.4 kHz (±3 dB) and an extremely robust design with shock resistance up to 10,000 g.

The sensors feature a lightweight, reliable anodised Aluminium housing with protection class IP67 and an integrated cable of configurable length and connector options. The accelerometers are available in uniaxial, biaxial and triaxial configuration. Custom versions on request.

The ECO CS range of Accelerometers for structural health montioring of bridges for Pylon sway or Deck monitoring. Integration of the output will measure speed, double integration will measure displacement. Contact us for more details on high accuracy, ultra low noise cable sway measurements using MEMS Accelerometers.

Due to their loss-free signal transmission, even in the case of very long cables, the sensors of the ASC ECO CS series are also used in civil engineering applications, such as infrastructure monitoring in rail transport or structural analysis of bridges.
