CD120 string potentiometer

Product Description

The CD120 String Potentiometer is a linear displacement sensor designed to accurately measure the movement or displacement of an object. It has a measuring range of up to 3000mm, providing a potentiometric output for easy integration into a wide range of applications.

This potentiometer offers high accuracy and precision with a resolution of 0.1% of full scale and a linearity option of ±0.10% of full scale. It also has a rugged, stainless steel wire that can retract and extend with ease, and a durable conductive plastic resistance track that ensures reliable and consistent results.

The CD120 String Potentiometer is compatible with a wide range of input voltages, including 5VDC, 10VDC, and 24VDC. It also has a maximum speed of up to 5 m/s for high-speed applications, and an operating temperature range of -20°C to +80°C. Additionally, it features a rugged, IP67-rated housing that protects it from environmental contaminants.

This linear displacement sensor is ideal for use in a wide range of applications, such as automotive testing, quality control, and robotics. Its compact and durable design, along with its high accuracy and precision, make it a reliable choice for engineers, scientists, and technicians.

Technical note: Recommended maximum draw wire extension length – 15 metres maximum

CD120 now in stock available to purchase on Strainsense Store.
