Distributed Data Acquisition Via Ethernet

Product Description

Many applications require more than one measurement device, sometimes even at different locations. The OXYGEN-NET option makes it possible to sum up all devices to one virtual measurement device. You only need a reliable network connection, and you can simply claim all available nodes and operate it from the main device.

OXYGEN-NET is easy to set up and can be used to combine several DEWE2/3 systems connected to the same ethernet network to one high channel count measurement system. DEWE2/3 systems combined to an OXYGEN-NET system can be synchronized and controlled with one Master unit.

The measurement screens on the Master unit and Slave units can be configured like on a standalone measurement unit. The data channels of a Slave unit can be configured via the Master unit.

After pressing the Record button on the Master unit, all transferred data channels and the data channels connected directly to the Master unit will be stored to one datafile on the Master unit.

The following topologies of synchronization and Data Transfer paths are supported within Oxyxgen. The main difference between these topologies is if the single nodes are synchronized via TRION-SYNC-BUS or TIMING modules,i.e. TRION-BASE , -TIMING or -VGPS boards.

• TRION-SYNC-BUS without TIMING
• TRION-SYNC-BUS with TIMING
• TIMING without TRION-SYNC-BUS
