Low Profile/Pancake Load Cells

Heavy duty Pan-cake load cell

• Ranges 0-10 kN to 1000 kN
• Output 2mV/V or voltage
• Accuracy 0.1% full scale
• High customisation

Heavy duty cylindrical load cell, fatigue

• Ranges 0-5 kN to 500 kN
• Output 1.5 mV/V or voltage
• Accuracy 0.25% full scale
• Suited for fatigue and crash testing

Pancake load cell, interchangeable

• Range from 100 N to 20000 N
• Output 1.5 mV/V or voltage
• Accuracy: 0.1% F.S.
• Interchangeable ranges

Low profile, Aluminium

• Range 0-500N to 200kN
• Output 2 mV/V
• Accuracy 0.25% full scale
• High natural frequency

Low profile pancake, fatigue rated

• Range 0-5kN to 1000kN
• Output 2 mV/V
• Accuracy 0.1% full scale
• Atex certification available

Compression load cell, high capacity

• Range 0-100 to 750 tonnes
• Output 2 mV/V, 4-20mA
• Accuracy 0.1% full scale
• IP68, Atex option
