High Frequency Response

Miniature, high frequency response

• Ranges from 0.3 to 350 bar gauge or abs
• Output mV
• Linearity up to ±0.5% FS
• Stainless steel construction

Miniature, dynamic response pressure sensor

• Ranges 1 to 350 bar gauge, sg, abs
• Output mV or 0.5 to 4.5V
• Linearity up to ±0.25% FS
• Titanium construction

Miniature, dynamic response pressure sensor

• Ranges 1 to 350 bar gauge, sg, abs
• Output 4-20mA, mV or voltage
• Linearity up to ±0.5% FS
• Stainless Steel construction

Miniature pressure sensor for high temperature

• Ranges 10 to 350 bar gauge, sg, abs
• Output 0-10mV
• Linearity ±0.25% FS
• -50 to 220 Deg C operating

Miniature pressure sensor for high bandwidth

• Ranges -1/+4 to 0-250 bar gauge, abs
• Outputs mV, 0.5 to 4.5VDC, 0-5VDC
• Accuracy 0.25% FS
• High frequency

Pore water pressure sensor

• Ranges 0-1 to 0-70 bar gauge or abs
• Output to 100mV
• Accuracy 0.25% FS
• Ceramic stones or bronze filters

Miniature, dynamic response pressure sensor

• Ranges 5 to 200 bar g, sg, abs
• Output mV/V
• Linearity up to ±0.35% FS
• IP67 option, or integral connector

Miniature pressure sensor

• Ranges 20 to 1000 bar gauge, sg, abs
• Output mV, 0.5 to 5V
• Linearity ±0.25% FS
• Stainless steel construction
